- Pulse operation for fast and convenient quick spins . Speed up to 15000rpm (15100×g)
- Brushless DC motor drive quickly to the target speed
- Smooth and quiet operation (noise ≤54dB)
- Automatic lid-lock and over-speed detection
- Passed rigorous explosion-proof test, certified with CE,cTÜVus, FCC
Specifications
|
Parameter
|
Value
|
|
Speed range
|
15000rpm(500- 15000rpm), increment: 100rpm
|
|
Max. RCF
|
15100×g, increment: 100×g
|
|
Speed accuracy
|
±20rpm
|
|
Rotor capacity
|
0.2mL/0.5mL/1.5mL/2mL×12
|
|
Run time
|
30sec-99min/Continuous
|
|
Acceleration/Braking time
|
11s↑/9s↓
|
|
Display
|
LCD
|
|
Power
|
Single-phase, 3A100W
|
|
Voltage/Frequency
|
AC100V-240V, 50Hz/60Hz
|
|
Noise level
|
≤54dB
|
|
Motor type
|
Brushless DC motor
|
|
Dimensions [WxDxH]
|
255×245×140mm
|
|
Weight
|
6kg
|
|
Safety performance
|
Door interlock, Over-speed detection, Over-temperature detection, Automatic internal diagnosis
|
|
Other functions
|
Speed/RCF switch, Short-time run function, sound-alert function
|
Accessories
2ml to 0.2ml rotor adapter as well as 2ml to 0.5ml rotor adapter to use in the rotors; are available, please ask us.
Tubes in each centrifugation run must be balanced. Failure to do so may result in damage to the equipment and injury to personnel.
